01
What is going up
People, a bed and its attendants, a pallet, or a car. This decides the product line before anything else does.
Products
Eight lift lines, plus escalators. Start with what has to move.
Most people arrive here knowing their building but not the machine, which is the right way round. Tell us what has to go up, and how much of the building already exists. The rest follows from those two answers.
Eight lift lines
Pick the machine, then see the number
Also available
Three more things we do
How to choose
Five questions that decide which lift you need
02
How many floors
Two stops and five stops are different machines above a certain point, not the same machine with more cable.
03
How much of the building exists
A shaft you can still draw is cheap. A shaft that has to be built is a civil cost. No shaft at all is a structure lift.
04
Pit and headroom
On a finished house these two measurements decide the drive type before budget gets a say.
05
How hard it will be used
Fifteen trips a day and three hundred trips a day are rated differently, and underrating a lift to win a quotation is why lifts fail early.
Compare
Which machine for which building
| Product | Typical capacity | Drive | Best for | From price at G+1 |
|---|---|---|---|---|
| Home lift | 250 kg / 4 person | Hydraulic, pitless traction or wall mounted | Finished houses | Rs 8.20 L |
| Passenger MRL | 408 kg / 6 person | Gearless MRL | Offices, apartments | Rs 7.43 L |
| Passenger MR | 544 kg / 8 person | Geared traction | Buildings with a machine room | Rs 8.15 L |
| Hospital | 1020 kg / 15 person | Geared traction | Beds and stretchers | Rs 9.85 L |
| Goods | 1000 kg | Geared traction | Warehouses, kitchens | Rs 6.15 L |
| Structure | 408 kg / 6 person | MRL in steel shaft | RWA, retrofit | Rs 10.35 L |
| Hydraulic | 272 kg / 4 person | Hydraulic pitless | Low rise, finished houses | Rs 8.95 L |
| Car elevator | 3000 kg | Hydraulic wide platform | Basement to podium | Rs 16.90 L |
| Escalators | By rise and width | 30° / 35° / moving walk | Retail and public floors | Quoted against your building |
The table cannot answer two questions. Whether your building will actually take the lift you want is a survey question. What the civil work will cost is your mason's number, not ours. We answer both, free, before you commit to anything.
Tell us what has to move. We will tell you which machine does it.
The survey is free. You get the product, the shaft drawings and an itemised number.
